FALCON — AI-Driven Fully Automated End-to-End Analog Circuit Design

About

Our Research Vision

Building a comprehensive AI ecosystem that automates every stage of analog circuit design — from specification to manufacturable silicon.

Designing analog and RF circuits remains one of the most expertise-intensive and time-consuming tasks in modern electronics development. Unlike digital design, which benefits from mature EDA automation, analog design still relies heavily on manual, iterative workflows guided by years of engineering intuition. Each stage — from selecting the right circuit topology, to tuning component parameters for target performance, to ensuring the design is physically realizable under layout constraints — demands deep domain knowledge and painstaking trial-and-error.

The FALCON research program addresses this fundamental bottleneck by developing a unified AI-driven framework for fully automated, end-to-end analog circuit design. Our work spans the complete design pipeline: foundational datasets and benchmarks for training ML models, supervised learning approaches for circuit parameter inference, a unified framework integrating topology selection with layout-constrained optimization, and EM-aware physical synthesis for translating netlists into manufacturable GDSII layouts. Together, these contributions form a cohesive research ecosystem advancing the state of the art toward truly autonomous analog design automation.

🔍

Topology Selection

Automatically selecting the optimal circuit architecture from a library of expert-designed topologies based on target performance specifications, guided by human design heuristics and ML classification.

⚙️

Parameter Optimization

Inferring precise component parameters through differentiable forward models — custom edge-centric graph neural networks that serve as learned surrogates for expensive industrial circuit simulators.

📐

Layout-Aware Design

Integrating physical layout constraints — parasitic effects, frequency-dependent EM behavior, and design rule compliance — directly into the optimization loop via differentiable layout cost functions.

🏭

Physical Synthesis

Translating optimized circuit netlists into manufacturable GDSII layouts through neural inductor modeling, intelligent P-Cell optimization, and automated placement and routing for RF circuits.

Approach

End-to-End Design Pipeline

Our core framework unifies topology selection, forward modeling, and layout-aware inference into a single differentiable pipeline — the first to do so at industrial scale.

01

Topology Selection

A lightweight MLP classifier maps target performance specifications to the most suitable circuit topology from a curated library of 20 expert-designed architectures, guided by human design heuristics.

MLP Classifier · >99% Accuracy

02

Forward Performance Modeling

A custom edge-centric Graph Neural Network serves as a differentiable surrogate for the Cadence Spectre simulator, mapping netlist-derived circuit graphs to 16-dimensional performance vectors.

Edge-Centric GNN · 16-dim Output

03

Layout-Aware Inference

Gradient-based optimization over the learned GNN recovers design parameters satisfying target specs under a differentiable layout cost capturing parasitic effects, EM behavior, and DRC constraints.

Differentiable Layout · <1s Inference

Milestones

Key Milestones

Evaluated on 1M+ Cadence Spectre-simulated mm-wave circuits across 20 topologies, our research program achieves state-of-the-art results across all design stages.

🎯

>99%

Topology Selection
Accuracy

📊

<10%

Average Relative
Prediction Error

⚡

<1s

Design Time
Per Instance

🔬

20

Expert-Designed
Topologies

🏆 Research Contributions

✓ First unified end-to-end framework for topology selection, parameter inference, and layout-aware optimization at industrial scale
✓ Layout-constrained inverse design within a single differentiable pipeline — a capability not supported by existing frameworks
✓ Largest foundry-grade analog circuit dataset: 1M+ Cadence-simulated circuits across 20 topologies
✓ EM-aware physical synthesis for complete netlist-to-GDSII layout generation
✓ Open-source code, datasets, and models under MIT license

⚙️ Technical Highlights

✓ Sub-second inference on standard hardware (MacBook CPU) — practical for real-world design workflows
✓ Edge-centric GNN that generalizes to unseen topologies with minimal fine-tuning
✓ 16-dimensional performance prediction covering gain, noise figure, bandwidth, power, and more
✓ Comprehensive ML benchmarks across transformers, SVRs, random forests, and GNNs for circuit design
✓ Neural inductor modeling with EM-accurate predictions across 1–100 GHz

Research

Research Ecosystem

A systematic research program building toward fully automated analog design — from foundational datasets to complete physical layout generation.

NeurIPS ML4PS 2024 2024

AICircuit: A Multi-Level Dataset and Benchmark for AI-Driven Analog Integrated Circuit Design

The foundational dataset and benchmark that enabled our research program. Introduces a comprehensive multi-level dataset of 7 core analog/RF circuits and 2 complex wireless transceiver systems, simulated with Cadence Spectre. Evaluates MLPs, Transformers, SVRs, and other ML models for circuit design tasks.

Asal Mehradfar, Xuzhe Zhao, Yue Niu, Sara Babakniya, Mahdi Alesheikh, Hamidreza Aghasi, Salman Avestimehr

arXiv GitHub

arXiv Preprint 2025

Supervised Learning for Analog and RF Circuit Design: Benchmarks and Comparative Insights

A comprehensive evaluation of supervised ML approaches for designing circuit parameters from performance specifications. Benchmarks diverse models from transformers to random forests, revealing that simpler circuits (LNAs) achieve 0.3% mean relative error while complex circuits (PAs, VCOs) benefit from deeper architectures.

Asal Mehradfar, Xuzhe Zhao, Yue Niu, Sara Babakniya, Mahdi Alesheikh, Hamidreza Aghasi, Salman Avestimehr

arXiv

NeurIPS 2025

Flagship 2025

FALCON: An ML Framework for Fully Automated Layout-Constrained Analog Circuit Design

The unified ML framework that brings it all together. FALCON integrates performance-driven topology selection, edge-centric GNN forward modeling, and gradient-based layout-aware parameter inference into a single end-to-end pipeline. Trained on 1M+ Cadence Spectre-simulated mm-wave circuits across 20 topologies, achieving >99% topology accuracy, <10% prediction error, and sub-second design time.

Asal Mehradfar, Xuzhe Zhao, Yilun Huang, Emir Ceyani, Yankai Yang, Shihao Han, Hamidreza Aghasi, Salman Avestimehr

arXiv GitHub NeurIPS OpenReview

ISCAS 2026 2026

EM-Aware Physical Synthesis: Neural Inductor Modeling and Intelligent Placement & Routing for RF Circuits

Extends the FALCON vision from schematic-level to complete physical layout generation. Features a neural inductor model with EM-accurate predictions across 1–100 GHz, intelligent P-Cell optimization for DRC compliance, and a complete placement and routing engine — enabling full netlist-to-GDSII automation for 22-nm CMOS RF circuits.

Yilun Huang, Asal Mehradfar, Salman Avestimehr, Hamidreza Aghasi

arXiv GitHub

Dataset

Datasets & Benchmarks

Our research is powered by large-scale, high-fidelity analog circuit datasets generated using industrial Cadence Spectre simulations, enabling reproducible AI-driven circuit design research.

FALCON Dataset Fully Automated Layout-Constrained Analog Circuit Dataset

NeurIPS 2025 1M+ Circuits

The largest foundry-grade analog circuit dataset to date. Contains over 1,000,000 Cadence Spectre-simulated circuit instances across 20 expert-designed topologies, with process fidelity, noise characteristics, and layout-dependent behavior of foundry-calibrated flows — far surpassing symbolic SPICE alternatives.

📦

Total Circuits

1,000,000+ simulated instances

🔧

Simulator

Cadence Spectre (foundry-calibrated)

🏗️

Topologies

20 expert-designed architectures

📏

Performance Vector

16-dimensional (gain, NF, BW, power, ...)

🏭

Fidelity

Foundry-grade with noise & layout effects

🔓

License

MIT — Open Source

🔌 Circuit Categories (5 Types, 20 Topologies)

Spanning core analog/RF building blocks

LNALow-Noise Amplifier

MixerFrequency Mixer

VCOVoltage-Controlled Oscillator

PAPower Amplifier

VAVoltage Amplifier

💻 GitHub Repository 📜 arXiv Paper

🧠

AICircuit Dataset A Multi-Level Dataset & Benchmark for AI-Driven Analog IC Design

NeurIPS ML4PS 2024 350K+ Circuits

The foundational dataset and benchmark that enabled the FALCON research program. AICircuit introduces a comprehensive multi-level dataset of 7 core analog/RF circuits and 2 complex wireless transceiver systems, simulated with Cadence Spectre. It evaluates MLPs, Transformers, SVRs, and other ML models for circuit design tasks — establishing rigorous baselines for AI-driven analog design.

🏗️

Circuit Types

7 core analog/RF + 2 transceiver systems

🔧

Simulator

Cadence Spectre (foundry-calibrated)

🤖

ML Models Evaluated

MLP, Transformer, SVR, and more

🎯

Scope

Multi-level: component to system-level

📚

Benchmark Tasks

Forward prediction & inverse design

🔓

License

MIT — Open Source

🔬 Multi-Level Design Hierarchy

From individual components to complete transceiver systems

LNALow-Noise Amplifier

MixerFrequency Mixer

VCOVoltage-Controlled Oscillator

PAPower Amplifier

TSVATwo-Stage Voltage Amplifier

CVACascode Voltage Amplifier

CSVACommon-Source Voltage Amplifier

TXTransmitter System

RXReceiver System

💻 GitHub Repository 📜 arXiv Paper

Citation

Cite Our Work

If you find our research useful, please consider citing the relevant papers.

FALCON — NeurIPS 2025

@inproceedings{Mehradfar2025FALCON,
  title     = {{FALCON}: An {ML} Framework for Fully Automated Layout-Constrained Analog Circuit Design},
  author    = {Mehradfar, Asal and Zhao, Xuzhe and Huang, Yilun and Ceyani, Emir and Yang, Yankai and Han, Shihao and Aghasi, Hamidreza and Avestimehr, Salman},
  booktitle = {The Thirty-ninth Annual Conference on Neural Information Processing Systems},
  year      = {2025}
}

AICircuit — NeurIPS ML4PS 2024

@inproceedings{Mehradfar2024AICircuit,
  title     = {{AICircuit}: A Multi-Level Dataset and Benchmark for {AI}-Driven Analog Integrated Circuit Design},
  author    = {Mehradfar, Asal and Zhao, Xuzhe and Niu, Yue and Babakniya, Sara and Alesheikh, Mahdi and Aghasi, Hamidreza and Avestimehr, Salman},
  booktitle = {Machine Learning and the Physical Sciences Workshop at NeurIPS 2024},
  year      = {2024}
}

Supervised Learning Benchmarks — 2025

@article{Mehradfar2025Supervised,
  title     = {Supervised Learning for Analog and {RF} Circuit Design: Benchmarks and Comparative Insights},
  author    = {Mehradfar, Asal and Zhao, Xuzhe and Niu, Yue and Babakniya, Sara and Alesheikh, Mahdi and Aghasi, Hamidreza and Avestimehr, Salman},
  journal   = {arXiv preprint arXiv:2501.11839},
  year      = {2025}
}

EM-Aware Physical Synthesis — ISCAS 2026

@inproceedings{Huang2026EMAware,
  title     = {{EM}-Aware Physical Synthesis: Neural Inductor Modeling and Intelligent Placement & Routing for {RF} Circuits},
  author    = {Huang, Yilun and Mehradfar, Asal and Avestimehr, Salman and Aghasi, Hamidreza},
  booktitle = {IEEE International Symposium on Circuits and Systems (ISCAS)},
  year      = {2026}
}
